Chapter one Development history of XLPE insulated cable
Chapter two Structure and material property of XLPE insulated cable
2. 1 Structure of XLPE insulated cable
2.2 Conductor material
2.3 Insulation material
2.4 Internal and external semiconductor screen layer of XLPE insulated cable
2.5 Metallic screen
Chapter three Calculated electric parameter of XLPE insulated cable with mathematical statistics theory
3.1 Theoretical basis
3.2 Confirm breakdown distribution of cable
3. 3 Analyses related to insulation thickness and breakdown electricfield
3.4 Design of 220kV XLPE cable construction
3.5 Analyses of tests
3.6 Estimate cable reliability in operation
3.7 Confirm operated cable reliability used in method o calculated expectation life
Chapter four Electrical parameter of XLPE insulated cable
4.1 Electrical field distribution of XLPE insulated cable
4.2 Conductor resistance of XLPE insulated cable
4.3 Inductance of XLPE insulated cable
4.4 Capacitance of XLPE insulated cable
4.5 Induced voltage of metallic screen layer （or metallic sheath） of XLPE insulated cable
4.6 Metallic sheath overvoltage of XLPE insulated cable
Chapter five Electric parameter of accessories on XLPE insulated cable
5.1 Electrical field distribution of accessories on XLPE insulated cable
5.2 Calculation and structure of stress control
5.3 Boundary property of accessories on XLPE insulated cable
5.4 Electrical calculation of terminal
5.5 Electrical calculation of joint
5.6 Shrinkage of XLPE insulated cable
……
Chapter six Confirm design parameter of XLPE insulated cable line
Chapter seven Confirm design parameter of accessories in XLPE insulated cable line
Chapter eight XLPE insulated cable installation and laying
Chapter nine XLPE insulated cable accessories installation
Chapter ten Connection and earthing of metallic sheath of XLPE insulated cable
Chapter eleven Hand-over test and prevention test of XLPE insulated cable
Chapter twelve Online monitoring of XLPE insulated cable
Chapter thirteen Detection of cable fault
Chapter fourteen Operation, maintenance, technology management and security controls of XLPE power cable
References
Author introduction
From using point of view, this book go into particulars all;erformance of the material and construction on XLPE insulated power cablefrom theoretical and performance calculation, and tell about the option,installation, operation, maintain, test on site, hand-over and prevention test, teststandard and standard demand over this base. This book also introduce the somemanagerial experiences used to XLPE insulated power cable on the Electric Power Supply Bureau, and analyse the development tendency of XLPE insulated cable.
The book is a studied and worked handbook of engineer necessity used onthe XLPE insulation cable, a reference book of engineer at the Electric PowerSupply Bureau in China.
